Product Overview
The LSA-071 is an adjustable roller lever type vertical limit switch designed for mechanical position detection, travel limit control, and machine operation feedback in industrial automation systems. The adjustable roller lever allows the actuator position to be matched with different machine structures and movement directions.
This page describes model LSA-071 only. It is suitable for conveyors, machine tools, doors, safety systems, moving mechanisms, and industrial equipment requiring flexible mechanical position sensing.
Product Display
The LSA-071 uses a vertical switch body with an adjustable roller lever actuator, sealed contact mechanism, mounting base, and cable connection structure. The adjustable lever design helps optimize contact position during installation.
Key Technical Data
| Item | LSA-071 |
|---|---|
| Product type | Vertical limit switch |
| Actuator type | Adjustable roller lever |
| Contact form | 1NO + 1NC snap-action |
| Operating force | 150g max. / approx. 1.47N |
| Release force | 50g min. / approx. 0.49N |
| Pre-travel | 30mm max. |
| Overtravel | 20mm min. |
| Trigger position | 22.5 degrees |
| Movement differential | 14 degrees max. |
| Total travel | 50mm min. |
Features
- Double-circuit 1NO + 1NC snap-action contact structure.
- Adjustable roller lever actuator for flexible mechanical position detection.
- High mechanical strength housing structure.
- Water-proof and oil-proof construction for industrial applications.
- Built-in contact mechanism for stable switching performance.
- Large travel range for reliable mechanical operation.
- Suitable for automation equipment, conveyors, safety systems, and machine control.
Drawing
Outline and Mounting Dimensions
The drawing provides the body dimensions, mounting position, roller lever adjustment range, and actuator movement clearance of the LSA-071. Confirm the mechanical contact direction and available travel space before installation.
Contact Form
LSA-071 uses a 1NO + 1NC snap-action contact structure. The contact state changes when the adjustable roller lever actuator is operated by a moving mechanical part.
The NO and NC contact logic should be selected according to the equipment control circuit and safety requirements.
Ratings
| Rated Voltage | Resistance Load NC | Resistance Load NO | Lamp Load NC | Lamp Load NO | Inductive Load NC | Inductive Load NO | Motor Load NC | Motor Load NO |
|---|---|---|---|---|---|---|---|---|
| 125VAC | 5A | 5A | 1.5A | 0.7A | 3A | 3A | 2A | 1A |
| 250VAC | 5A | 5A | 1A | 0.5A | 3A | 3A | 1.5A | 0.8A |
| 8VDC | 5A | 5A | 3A | 3A | 5A | 4A | 3A | 3A |
Specifications
Electrical
| Contact resistance | 25 mΩ max. initial value |
| Insulation resistance | 100 MΩ min. at 500VDC |
| Dielectric strength | 1000VAC between same polarity terminals; 1500VAC between current and non-current parts |
Mechanical
| Operating speed | 5mm to 0.5m/s |
| Operating frequency | Electrical: 30 operations/min |
| Vibration | 10-55Hz, 1.5mm double amplitude |
| Shock | Mechanical durability approx. 100G; malfunction approx. 30G |
Environmental
| Ambient temperature | -20°C to +70°C, with no icing |
| Humidity | <95% RH |
| Degree of protection | IP66 |
Operating Characteristics
| Parameter | Description | LSA-071 |
|---|---|---|
| OF | Operating force | 150g / approx. 1.47N |
| RF | Release force | 50g / approx. 0.49N |
| PT | Pre-travel | 30mm |
| TP | Trigger position | 22.5 degrees |
| MD | Movement differential | 14 degrees |
| OT | Overtravel | 20mm |
| TT | Total travel | 50mm |
Selection Guide
Actuator Type
Select LSA-071 when an adjustable roller lever actuator is required to match different machine layouts and movement directions.
Mechanical Stroke
Confirm the available movement range. LSA-071 provides 30mm pre-travel, 20mm overtravel, and 50mm total travel for flexible operation.
Electrical Load
Check voltage, current, load type, and contact logic before selection. Consider surge current for inductive and motor loads.
Installation Environment
The housing is suitable for general industrial environments with dust, oil mist, and moisture exposure when correctly installed.
Application Matching
LSA-071 is suitable for conveyors, machine tools, doors, safety systems, and industrial automation equipment.
